Factory made hot-sale Inverter Screw Air Compressor - SPY7090120 Continuous Pre-expander – WELLEPS Detail:

eps machine

Main Features

1.Feeding, expander, filtrating, crushing, transport to silos automatically

2.With first and second expansion, the first time filling adopt frequency conversion feeding device, guarantee the stability of feeding

3.Uniform foaming, foam density range is 6-35g/l

4.Material barrel inside and outside, fluidized bed dryer made of stainless steel, in order to maintain the durable use and stable performance

5.Electrical protection device

6.Adopt Japanese reducing valve

batch pre-expander machine



batch pre-expander machine

Technical Data

Item PSY70 PSY90 PSY120
Expansion Chamber Diameter φ700mm φ900mm φ1200mm
Volume 0.6m³ 1.2m³ 2.2m³
Useable Volume 0.4m³ 0.8m³ 1.5m³
 Steam Entry DN20 DN25 DN50
Consumption 80-100kg/h 100-150kg/h 150-200kg/h
Pressue 0.6-0.8MPa 0.6-0.8MPa 0.6-0.8MPa
Compressed Air Entry DN15 DN20 DN20
Pressure 0.6-0.8MPa 0.6-0.8MPa 0.6-0.8MPa
Drainage Condensate φ20mm φ20mm φ20mm
         Throughput 15g/l 100kg/h 150kg/h 250kg/h
20g/l 120kg/h 200kg/h 300kg/h
25g/l 150kg/h 250kg/h 410kg/h
30g/l 200kg/h 300kg/h 500kg/h
Material Conveying Line φ150mm φ150mm φ150mm
Power 8.93kW 9.73kW 14.83kW
Density  First expansion 12-30g/l 12-30g/l 14-30g/l
Second expansion 8-11g/l 8-11g/l 8-13g/l
Outside Dimensions L×W×H 4700×2660×2600mm 4700×2930×32000mm 4905×4655×3250mm
Weight 1300kg 1500kg 1800kg
Room Height Required 3000mm 3000mm 3000mm

Application

batch pre-expander machine








Product detail pictures:

Factory made hot-sale Inverter Screw Air Compressor - SPY7090120 Continuous Pre-expander – WELLEPS detail pictures

Factory made hot-sale Inverter Screw Air Compressor - SPY7090120 Continuous Pre-expander – WELLEPS detail pictures

Factory made hot-sale Inverter Screw Air Compressor - SPY7090120 Continuous Pre-expander – WELLEPS detail pictures
