factory low price Ejector - oil free vacuum pump – WELLEPS Detail:

Machinery Introduction

Central Vacuum Energy System, EPS/EPP-specific industry-designed vacuum system can perfectly solve your worries.

1. High vacuum efficiency and stable vacuum degree. Long service life, simple maintenance and low maintenance cost.
2. Frequencyconversion control saves more than 50% energy than ordinary water ring vacuum pumps.
3. Joseph Supporting the EPS industry dedicated tower condensing system independently developed and designed , the entire system is hot-dip galvanized, energy-saving and efficient, truly maintenance-free and maintenance-free, and completely solves the problem of short service life and difficult vacuum maintenance of ordinary towers.

Product benefits

1. Energy saving: the double-stage oil-free vacuum pump can save 40%-60% energy than the traditional water ring vacuum pump, with high efficiency and low power consumption. The efficiency is 1.8 times higher than the water ring vacuum pump. A year of rapid return of the extra cost.

2. Environmental protection: a large number of water ring vacuum pump and oil seal vacuum pump used in the market produce a large number of sewage and waste oil, cause pollution to the environment, while our oil-free double stage vacuum pump using special technology, it’s with no pollution to the environment.

3. High-end: we adhere to the high-end quality line, our production process is checked layer by layer, our technology of permanent magnet frequency intelligent operation is stable and reliable.

4. Oil-free advantages:
*Adopt German SKF heavy load bearing and chisel wheel, stable operation;
*Adopt imported high-end machining center to process host machine, high precision and high efficiency;
*Low maintenance cost, reduce the operating cost;
*Over temperature anti-corrosive coating design, long service life at high temperature.

5. Pump with High efficiency permanent magnet motor (with independent fan).

6. Advantages of intelligent controller: Intelligent control system, improve the high performance of the vacuum pump system controller, realize the remote control of the Internet of things, multiple machines automatically switch the working mode, humanized man-machine interface.

Technical Data

Model	Vacuum（Kpa）	Capacity m³/min	Power KW	Water Consumption m³/h	Max temperature of ambient	Noise DB	Weight Kg	Dimensions （mm）
WE-15PM	-50Kpa ~-80Kpa	2.05-14.40	15	0.15	≤46	76±2	1400	1450×1050×1200
WE-22PM		3.21-22.52	22	0.20		78±2	1500	1670×1200×1350
WE-30PM		4.72-31.08	30	0.20		78±2	1800	1930×1290×1500
WE-37PMI		5.72-40.10	37	0.20		79±2	1900	1930×1290×1500
WE-45PM		7.32-51.23	45	0.20		82±2	2080	2100×1500×1600
WE-55PM		8.61-60.29	55	0.30		82±2	2800	2200×1350×1800
WE-75PM		11.70-81.88	75	0.35		87±2	3000	2100×1700×1760
WE-90PM		24.15-99.75	90	0.37		89±2	3600	2600×1350×2100
WE-110PM		30.45-121.80	110	0.40		89±2	3750	2600×1350×2100
WE-132PM		36.75-152.25	132	0.50		91±2	4300	2600×1350×2100
WE-160PM		48.30-194.25	160	0.55		91±2	4900	2950×1850×2100
WE-185PM		65.10-262.50	185	0.80		92±2	5600	2950×1850×2100
WE-220PM		78.75-312.90	220	0.83		92±2	5900	3200×2050×2400
WE-250PM		86.10-341.25	250	0.86		92±2	7000	3200×2050×2400

Data comparison

Vacuum pumps	Model	Power（kw）	Flow（m³/min)	Water Consumption（Tons/year）	Annual water saving	Power consumption (degrees/year)	Save electricity consumption every year	Save electricity bills every year
Vacuum energy system	WE-15PM	15KW	13.71	1200	12400	120000	56000	$8,000
Water ring vacuum pump	2BE1 153-0	22KW	11	13600	12400	176000	56000	$8,000
Vacuum energy system	WE-22PM	22KW	21.45	1600	19200	176000	120000	$20,000
Water ring vacuum pump	2BE1 203-0	37KW	18.7	20800	19200	296000	120000	$20,000
Vacuum energy system	WE-30PM	30KW	29.6	1600	33600	240000	200000	$30,000
Water ring vacuum pump	2BE1 252-0	55KW	30.8	35200	33600	440000	200000	$30,000
Vacuum energy system	WE-37PM	37KW	38.19	1600	33600	296000	304000	$50,000
Water ring vacuum pump	2BE1 252-0	75KW	40.8	35200	33600	600000	304000	$50,000
Vacuum energy system	WE-45PM	45KW	48.79	1600	40000	360000	360000	$60,000
Water ring vacuum pump	2BE1 253-0	90KW	47.8	41600	40000	720000	360000	$60,000
Vacuum energy system	WE-55PM	55KW	57.42	2400	39200	440000	440000	$70,000
Water ring vacuum pump	2BE1 253-0	110KW	50.3	41600	39200	880000	440000	$70,000
Vacuum energy system	WE-75PM	75KW	77.98	2800	62800	600000	456000	$72,000
Water ring vacuum pump	2BE1 305-O	132KW	77.5	65600	62800	1056000	456000	$72,000
Vacuum energy system	WE-90PM	90KW	95	2800	69200	720000	560000	$80,000
Water ring vacuum pump	2BE1 353-0	160KW	91.7	72000	69200	1280000	560000	$80,000
